Ubiquiti | Unifi Access Point | UAP-U7-PRO | WiFi 7 ** PoE Injector not included **

$489.21 + GST

  • Four-stream high-efficiency Wi-Fi 6 technology
  • 5 GHz band 4×4 MU-MIMO and OFDMA with radio rate of 2.4 Gbps
  • Powered with 802.3at PoE (PoE injector not included)
Category:

Description

Ubiquiti Unifi UAP-U6-PRO – WiFi 6 Pro – Access Point

Introducing the Ubiquiti Unifi WiFi 7 U7-PRO Access Point, a cutting-edge solution designed to elevate your wireless network experience. With blazing-fast speeds of up to 9.3Gbps over-the-air, powered by PoE+ technology, and managed seamlessly through UniFi Network 8.0.26 and later, this access point is the pinnacle of performance and convenience. Pair it effortlessly with a UniFi PoE switch featuring 2.5GbE performance and PoE+ output for optimal results.

FEATURES

  • Over-the-air speed of up to 9.3Gbps for lightning-fast connectivity
  • PoE+ powered (NO POE injector included) with a 2.5GbE uplink for efficient and streamlined installation
  • Fully backwards compatible with WiFi 6E and earlier devices, ensuring versatility
  • Robust hardware design with a durable polycarbonate and metal enclosure
  • Managed with UniFi Network 8.0.26 and later, providing intuitive control and monitoring

SPECIFICATIONS

  • Dimensions: Ø206 x 46mm
  • Weight: 680g
  • Enclosure Material: Polycarbonate, metal
  • Mount Material: Stainless steel (SUS304), galvanized steel (SGCC)
  • Networking Interface: 1 x 1/2.5GbE RJ45 port
  • Management Interface: Ethernet
  • Power Method: PoE+
  • Power Supply: UniFi PoE switch (not included)
  • Supported Voltage Range: 44—57V DC
  • Max. Power Consumption: 21W
  • Max. TX Power:
    • 2.4 GHz: 22dBm
    • 5 GHz: 26dBm
    • 6 GHz: 23dBm
  • MIMO:
    • 2.4GHz: 2 x 2
    • 5GHz: 2 x 2
    • 6GHz: 2 x 2
  • Throughput Rate:
    • 2.4GHz: 688Mbps
    • 5GHz: 2882Mbps
    • 6GHz: 5765Mbps
  • Antenna Gain:
    • 2.4GHz: 4dBi
    • 5GHz: 6dBi
    • 6GHz: 5.8dBi
  • LEDs: White/blue
  • Button: Factory reset
  • Mounting: Wall/ceiling (Included)
  • Ambient Operating Temperature: -30 to 60°C
  • Ambient Operating Humidity: 5 to 95% non-condensing
  • Certifications: CE, FCC, IC
  • WiFi Standards: 802.11a/b/g/n/ac/ax/be (WiFi 7)
  • Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
  • BSSID: 8 per radio
  • VLAN: 802.1Q
  • Advanced QoS: Per-user rate limiting
  • Guest Traffic Isolation: Supported
  • Concurrent Clients: 300+
  • Supported Data Rates:
    • 802.11a: 6, 9, 12, 18, 24, 36, 48, 54Mbps
    • 802.11b: 1, 2, 5.5, 11Mbps
    • 802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
    • 802.11n: 6.5Mbps to 300Mbps (MCS0 – MCS15, HT 20/40)
    • 802.11ac (WiFi 5): 6.5Mbps to 1.7Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
    • 802.11ax (WiFi 6/6E): 7.3Mbps to 2.4Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
    • 802.11be (WiFi 7): 7.3Mbps to 5.7Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320)
  • Application Requirements:
    • UniFi Network: Version 8.0.26 and later
    • UniFi OS: Version 3.2 and later
